56mm Kiosk Label Printer LP-562 Embedded Thermal Module

LP-562 is a new label printer designed by Cashino and it's widely used for printing labels in medical device & weighing scales

Payment:
EXW Xiamen
Product origin:
Xiamen China
Color:
Black
Shipping port:
Xiamen Port
Lead Time:
7 working days

Product details
Product specification
Application

Low noise direct thermal printing
With label peeling function and backing
paper recycling function
Open channel design (easy to install the medium)
Support large diameter paper roll ф100mm(Max)

product model		LP-562
Printing	Print mode	Direct Thermal
	Print width	56mm
	Print resolution	203dpi
	Print speed max.	120mm/s
Storage	SRAM	2M bytes
Storage	Flash	256K bytes
Paper	Type	Thermal label paper
	Width	30~62mm
	Roll paper diameter（O.D）	100mm
	Thickness	0.06mm~0.15mm
Character set	Font	Font A:12x24;Font B:9x17 GBK:24x24
Character set	Code page	48
Barocde	1D barocde	UPC-A, UPC-E, JAN/EAN8, JAN/EAN13, CODE39, ITF, CODEBAR, CODE128, CODE93
Barocde	2D barocde	QRCode,PDF417
Interface	Standard	USB+RS232/TTL
Interface	Optional	LAN
Sensor	Standard	TPH overheat detection, platen in position detection, paper existing detection, paper taken detection, seam mark detection
Sensor	Optional
Reliability	Cutting method	Peel off
	Cutter life
	TPH life	100km
Power Adapter	AC	AC100V-240V 50/60Hz
Power Adapter	DC	DC24V/2A
Cash drawer control
Dimensions (WxLxH)mm		267134107mm
Weight		1.6kg
Emulation(Compatiable)		TSPL、ESC/POS
Software	Driver	Windows Driver
Software	SDK	K-Lalel editor,Android SDK,Windows SDK Andoid SDK
Environment	Temperature	Operating:0°C~45°C Storage:-20°C ~ 60°C
Environment	Humidity	Operating:20%RH~85%RH Storage:10%~90%RH
