2-inch Panel printer with cutter

EP-260CH 58mm width high-speed mini panel thermal printer with auto-cutter

EP-260CH 58mm width high-speed mini panel thermal printer with auto-cutter

24VDC,150mm/s,Serial+USB


  • Item No.:

    EP-260CH
  • Payment:

    Paypal, Western Union, T/T
  • Product origin:

    Xiamen, China
  • Color:

    Black/White
  • Shipping port:

    Xiamen
  • Lead Time:

    1-2weeks
  • Product details

  • Product specification

  • Application

EP-260CH 58mm width high-speed mini panel mount thermal printer with auto-cutter


EP-260CH is a mini panel receipt printer with auto cutter. It could be embedded to any kind of kiosk, instruments and meters.


Feature:

1. Interface:(RS232/TTL)+USB

2. Power supply: DC24V

3. Auto cutter: full/partial cut

4. Easy paper loading

5. Low noise thermal printing

6. Front panel make paper replacement easily

7. Color:Black/White






Company Information:

We are a professional manufacturer of thermal printers since 2011.Our main products are handheld thermal printer, impact dot matrix printer, panel thermal printer, kiosk ticket printer, POS receipt printer and label barcode printer, etc. We have a wealth of in dependent research and experience, which can effectively meet different customers ODM requirements and help achieve printing simply, efficiently and economically. Currently, Our products are exported to Southeast Asia, South Asia, South & North America, Middle East and Europe, etc.

mobile printer



Our Services:

portable bluetooth printer


FAQ:

Q: About samples

A: Samples are available for testing.

Q: Delivery date.

A: All the printers for samples are in stock, can ship it within 2 days after payment received. For bulk order

delivery date approximately 2 weeks.

Q: Payment terms

A: Paypal, western union, T/T in advance, or order in aliexpress.

Q: Warranty

A: One year warranty. During warranty period, the damage caused by non-human factor, CASHINO will be responsible for the free repair. Overdue warranty period, CASHINO will continue to provide services with reasonable price to the customer.


Specification:


Model No. EP-260CH
Print Printing method Thermal Line Printing
Printing speed 150mm/s
Resolution 203dpi(8dots/mm)
Printing width 48mm
Character Character Set ASCII,GBK,BIG-5 etc.
Print Font ANK:9×17,12×24,Chinese:24×24
Character per line Font A:32;Font B:42
Paper spec. Paper Type Thermal Paper
Paper Width 57.5±0.5mm
Paper Thickness 0.055-0.09mm
Paper Roll Diameter Max:60mm
Roll Core Inner Diameter 13mm(min)
Reliability TPH 100km or more(12.5% print ratio)
Cutter 1,000,000 cuts or more
Cutting Method Full and Partial cut
Interface Serial(RS232/TTL)+USB, Cash Drawer port (optional)
Power Supply DC24V, 2A(average) , Peak:5A
Barcode 1D UPC-A,UPC-E,EAN-13,EAN-8,CODE39,ITF25,CODABAR,
CODE93,CODE128
2D PDF417,QR Code
Physical Outline Dimension (WxLxH) 102×115.5×66mm
Installation Port Size(WxL) 96.3×110mm
Insert Depth 56mm
Color Black/White
Environment Operating Temp 0°C~50°C
Operating Humidity 10%~80%
Storage Temp -20°C~60°C
Storage Humidity 10%~90%

Application:

1. Medical Equipment

2. Measuring equipment

3. Security Equipment

4. Analyzing Instrument&Meter

5. Kiosk
