Cashino CSN-58V Thermal Receipt Printer Desktop POS Printer 180mm/s DC12V/24V USB/BT/WiFi/LAN
Item No.:
CSN-58VPayment:
PayPal,Western Union,T/TProduct origin:
Xiamen,ChinaShipping port:
Xiamen,China2" POS Printer
1. Three-Dimensional and fashionable appearance
2. Big gears, big motor
3. It can print on and off the table,horizontally and vertically
4. Support 1D and 2D code printing
5. Paper rolls with a width of 58mm and a diameter of 60mm
| Model | CSN-58V | |||
| Print method | Line thermal printing | |||
| Printing speed | Max:90mm/s | |||
| Resolution | 203dpi(8dots/mm) | |||
| Eefective printing width | 48mm | |||
| Character | Character set | ASCII code, GBK, etc | ||
| Print font | ASCI：(12*24、16*18、) Chinese：（24*24） | |||
| Paper roll specification | Paper type | Thermal paper | ||
| Paper width | 57.5±0.5mm | |||
| Roll diameter | Max:60mm | |||
| Roll paper thickness | 0.055-0.09mm | |||
| Temperature detection of TPH | Thermistor | |||
| Out of paper detection | Photoelectric detection | |||
| Barcode | One dimensional code | UPCA、UPC-E、JAN13(EAN13)、JAN8(EAN8)、CODE39、ITF、CODABAR、CODE128、CODE93 | ||
| QR code | QR CODE | |||
| Communication mode | USB (square port) / Bluetooth/LAN/WIFI | |||
| Print instruction | ESC/POS | |||
| Driver | Windows Driver/Linux Driver/Windows/Android SDK | |||
| physical property | (L * W * H) | 150*120*110mm | ||
| Color | Black | |||
| Power Supply | Input | AC 110V/220V ,50-60HZ | ||
| Output | DC 12V /2A | |||
| Cashbox | 12V /1A | |||
| Environment | working temperature | 0°C~50°C | ||
| Working humidity | 10%~80%RH(No Moisture) | |||
| Storage temperature: | -20°C~60°C | |||
| Storage humidity | 10%~90%RH(40°C) | |||
1. Retail store
2. Supermarket
3. Cinema
4. Restaurant
If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
