Products
Home RECEIPT PRINTERS

3-inch/80mm Thermal Series

CSN-80V 80mm Thermal Receipt POS Printer support page mode printing

CSN-80V 80mm Thermal Receipt POS Printer support page mode printing

RS232C+USB+LAN interface, 8M bytes flash, up to 250mm/s, DC24V

  • Item No.:

    CSN-80V
  • Payment:

    Paypal, Western Union, T/T
  • Product origin:

    Xiamen, China
  • Color:

    Black
  • Shipping port:

    Xiamen
  • Lead Time:

    1-2weeks
  • Product details

  • Product specification

  • Application

80mm Serial+USB+LAN thermal receipt pos printer



CSN-80V pos receipt printer is a compact,fast and advanced receipt pos machine printer, and bar code printer. enabling you to produce high quality receipts quickly and easily. With an easy maintenance cutter and patented long life printing (LLP) technology, capable of extending print life to over 100km.Features include drop-in paper loading, RS232,USB,LAN three ports, auto cutter and a long life thermal print head.



Feature:

1). High printing speed, up to 250mm/s, easy to maintain, improve work efficiency.
2). Low noise, high speed image&characters printing
3). Easy paper loading, with auto cutter,partial cut
4). Serial/USB/Ethernet interface optional.(Support two in one, or three in one)
5). Compatible with EPSON ESC/POS command sets.
6). Support paper out alarm and print prompt
7). Driver compatible: Win2000/WinXP/Windows7/Windows10/Linux




CSN-80V 80mm Thermal Receipt POS Printer support page mode printing

Company Information:

We are a professional manufacturer of thermal printers since 2011.Our main products are handheld thermal printer, impact dot matrix printer, panel thermal printer, kiosk ticket printer, pos printer and label barcode thermal printer, etc. We have a wealth of in dependent research and experience, which can effectively meet different customers ODM requirements and help achieve printing simply, efficiently and economically. Currently, Our products are exported to Southeast Asia, South Asia, South & North America, Middle East and Europe, etc.

mobile printer

Our Services:

portable bluetooth printer



FAQ:

Q: About samples

A: Samples are available for testing.

Q: Delivery date.

A: All the printers for samples are in stock, can ship it within 2 days after payment received. For bulk order

delivery date approximately 2 weeks.

Q: Payment terms

A: Paypal, western union, T/T in advance.

Q: Warranty

A: One year warranty. During warranty period, the damage caused by non-human factor, CASHINO will be responsible for the free repair. Overdue warranty period, CASHINO will continue to provide services with reasonable price to the customer.

Specification:


Model No. CSN-80V
Print Method Thermal line printing
Print Speed Max.250 mm/sec
Effective Print Width 72mm
Thermal paper roll Paper width:80mm
Max.80mm(O.D)
Paper thickness:0.055-0.09mm
Resolution 203dpi
Reliability TPH life:100km
Cutter life:1 million cuts or more
Character size (ANK Character):12×24 dots,1.5(width)×3.00(height)mm
(Jan/traditional form):24×24 dots,3.00(height)×3.00(high)mm
Characters Set ANK:Font A:12x24dots
Font B:9x17dots
Jan/traditional form:24x24dots
Barcode type UPC-A,UC-E,JAN13(EAN13),CODABAR,ITF,CODE39,CODE93,CODE128
PDF417,QR Code
Memory flash  8M bytes
Interface RS232C+USB+LAN
Auto-Cutter Full cut and Partial cut by command
Cashbox Control 24V/1A
Power supply DC24V/2.0A
Printing command Compatible with ESC/POS command set
Dimension (WxLxH) 148x198x145mm
Work environment Temperature 0°C~45°C;Relative humidity:10%~80%
Store environment Temperature-10°C~60°C;Relative humidity:10%~90%
Driver/SDK Windows Driver, Linux Driver, Android SDK, Windows SDK



Application:


1). Supermarket
2). Convenience stores
3). Restaurant
4). Bookstore
